There's more than one way to make a hard drive copy, but when time is money, a HDD duplicator is the best option. It's faster and simpler to utilize a HDD duplicator when duplicating multiple disks. A hard drive duplicator is designed specifically for making one or more copies, often without tying up a computer that might be needed for other functions. Using HDD duplicating software packages are typically much more complicated and time-consuming to use compared to the few button pushes it takes to clone an HDD using a duplicator.

Nowadays, it only takes minimal effort for end users to backup, archive and duplicate data on a HDD by utilizing HDD Duplicator.

For some organizations and individuals that work with hard drives on a regular basis turn to HDD duplicators for fast and accurate copies, increasing productivity and reducing costs. JMicron provides a simple, fast and reliable drive copying solution without using computer. The controller is suitable for any SATA HDD to be connected with the source and target port.


The duplicator conducts data verification after each duplication work completes, while the machine can also provide additional functions, such as:

  • HDD formatting
  • HDD sanitizers
  • Works as dock for multiple HDDs when directly connect to PC host

JMicron's Solution

JMicron has provided a series of HDD duplicator controllers to the industry for years. The products can supports a variety of configuration for clients to build a HDD duplicator or an external HDD dock when works with PC host. Furthermore, most of products support Port Multiplier and hardware RAID engines in order to accelerate the performance.

The JMB391 is a best-in-class selection for a 1:4 high-speed and high-reliability HDD duplicator. The controller supports a 1:5 SATA Port Multiplier with RAID 0/1/10 hardware capability. The performance of data duplication can be accelerated by its hardware RAID engines.



Block Diagram of JMB391



Solutions for HDD Duplicator

JMS562

  • USB 3.0 + eSATA 6Gbps to Dual SATA 6Gbps
  • RAID 0 / 1 / JBOD
  • Support 1:2 HDD copy function

JMS561U

  • USB 3.0 to Dual SATA 6Gbps
  • CLONE supported
  • Support 1:1 HDD copy function

JMB394

  • 1 to 5 ports SATA 3Gbps Port Multiplier
  • RAID 0 / 1 / 3 / 5 / 10 / JBOD / CLONE
  • Configurable eSATA and LCM support

JMB391

  • 1 to 5 ports SATA 3Gbps Port Multiplier
  • RAID 0 / 1 / 10 / JBOD
  • Configurable eSATA specification
